Heater cables
Which heater cable fits your VW? Look up your model and production period, check the length and version and click the part number to go straight to the product.
| Part number | Length | Description | Production start | Production end |
|---|---|---|---|---|
| Beetle / Karmann Ghia / Type 3 | ||||
| 0930-030 | 2843 mm | Beetle | 49- (162 444-) | -51 (-243 730) |
| 0930-040 | 2668 mm | Beetle | 51- (243 731-) | -07/55 (-929 745) |
| 0930-05 | 3670 mm | Beetle and Karmann Ghia | 04/55- (929 746-) | -10/62 (-5 199 979) |
| 0930-06 | 3665 mm | Beetle and Karmann Ghia | 11/62- (5 199 980-) | -07/64 (-6 502 399) |
| 0930-070 | 1440/1459 mm | Beetle | 08/64- (115 000 001-) | -07/72 (-112 3200 000) |
| 0930-080 | 1368/1378 mm | Beetle | 08/72- (113 2000 001-) | end of production |
| 0930-100 | 1375-1389 mm | Beetle 1303, Type 3 | Beetle 1303 08/72-, Type 3 08/66- | Beetle 1303 - 07/74, Type 3 end of production |
| 0930-110 | 1342 mm | Beetle 1303 | 08/74- | end of production |
| 0930 | universal | Beetle and Karmann Ghia | 08/65- | end of production |
| 0930-150 | 998 mm | Beetle | 08/64- (115 000 001-) | -07/72 (-112 3200 000) |
| 0930-160 | 905 mm | Beetle heater cable under rear seat | 08/72- (113 2000 001-) | end of production |
| Bus T1 / T2 | ||||
| 0931-020 | 5715 mm | Bus T1/T2 | 03/55- (20-117902-) | -07/67 |
| 0931-025 | 5750 mm | Bus T1/T2 heater cable for walkthrough | 03/55- (20-117902-) | -07/67 |
| 0931-100 | 4115 mm | Bus T1/T2 1600 cc heater cable left LHD | 08/67- | -07/71 |
| 0931-110 | 4130 mm | Bus T1/T2 1600 cc heater cable left LHD | 08/71- | -07/72 |
| 0931-115 | 4126 mm | Bus T1/T2 17/18/2000 cc heater cable left LHD | 08/71- | -07/72 |
| 0931-120 | 4115 mm | Bus T1/T2 1600 cc heater cable left LHD | 08/72- | -07/79 |
| 0931-125 | 4100 mm | Bus T1/T2 17/18/2000 cc heater cable left LHD | 08/72- | -07/79 |
| 0931-150 | 4205 mm | Bus T1/T2 1600 cc heater cable right LHD, RHD | LHD 08/67- | LHD -10/68, RHD -07/71 |
| 0931-160 | 4320 mm | Bus T1/T2 1600 cc heater cable right LHD | 11/68- | -07/71 |
| 0931-175 | 4313 mm | Bus T1/T2 17/18/2000 cc heater cable right LHD | 08/71- | -07/72 |
| 0931-180 | 4310 mm | Bus T1/T2 1600 cc heater cable right LHD | 08/72- | -07/79 |
| 0931-185 | 4225 mm | Bus T1/T2 17/18/2000 cc heater cable right LHD | 08/72- | -07/79 |
| 0931-215 | 4330 mm | Bus T1/T2 17/18/2000 cc heater cable left RHD | 08/71- | -07/72 |
| 0931-220 | 4330 mm | Bus T1/T2 1600 cc heater cable left RHD | 08/72- | -07/79 |
| 0931-225 | 4280 mm | Bus T1/T2 17/18/2000 cc heater cable left RHD | 08/72- | -07/79 |
| 0931-270 | 4383 mm | Bus T1/T2 17/18/2000 cc heater cable right RHD | 08/71- | -07/72 |
| 0931-280 | 4465 mm | Bus T1/T2 1600 cc heater cable right RHD | 08/72- | -07/79 |
| 0931-285 | 4465 mm | Bus T1/T2 17/18/2000 cc heater cable right RHD | 08/72- | -07/79 |
| Bus T3 | ||||
| 0932-150 | 4245 mm | Bus T3, heater cable right LHD CU, CV | 05/79- | -12/82 |
| 0932-160 | 4205 mm | Bus T3, heater cable right LHD CT, CZ | 05/79- | -12/82 |
| 0932-200 | 4565 mm | Bus T3, heater cable left RHD CU, CV | 05/79- | -12/82 |
| 0932-250 | 4670 mm | Bus T3, heater cable right RHD CU, CV | 05/79- | -12/82 |
| 0932-260 | 4640 mm | Bus T3, heater cable right RHD CT, CZ | 05/79- | -12/82 |
| 0932-510 | 920 mm | Bus T3, central dashboard heater cable, LHD, all water-cooled | 08/82- (24-D-000-001-) | end of production |
LHD = left-hand drive, RHD = right-hand drive.
Not sure which heater cable you need? Send us your model and year and we'll gladly help you out.
Get in touch
